• G32 Threading Cycle Fanuc

Contents. Thread Cutting Possibilities with G33 / G32 Threading G-Code.

Longitudinal thread. Transverse thread. Tapered thread. Single and Multiple Start threads with a constant pitch. Variable pitch and taper angles by Chaining thread cutting blocks. No doubt G33 is not widely used because we prefer to use a threading cycle (see ) instead.

G32 Threading Cycle Fanuc

1. G32 Cycle Parralel Threading For ISO Program on Mazak Machine Threading cycle G32 X5.0 5.0 = 1st pass Diameter Z10.0 10.0 = Thread length F0 8 0.8 = l.
2. Threading Methods There. The traditional threading method uses G32/G33 codes. These commands require four lines of program code for each thread pass.

But the flexibility and variety G33 gives us a threading cycle can’t. Threading with G33 / G32 G Code G33 is used for thread cutting, but with G33 we can just make a single threading cut. This all mean that you yourself have to do all the work of threading tool positioning.

May 24, 2016 I've used G32 for threading before and it worked fine. G32 threading problems. Because I can use my cadcam to program this.

Sequence of Operation for G-Code G33 / G32 Here is a sequence of operations for cutting longitudinal threads with G33. Take the threading tool to the start point.

(G00). Make a threading cut with G33. Take tool back in x-axis (G01 or G00). Make a rapid traverse in z-axis to the thread start point (G00).

Travel the threading tool in x-axis a bit more deeper (G01). Make second threading cut with G33. And again and again the sequence is repeated until the thread depth is complete.
